Battery For Solar Power System Home Energy

Battery for solar power system home energy：

Lithium batteries are a class of high-performance rechargeable cells that have become an integral part of our daily lives. They are known for their compact size, lightweight, and high energy-to-weight ratio, which makes them ideal for powering portable electronic devices and electric vehicles.

The energy solar system have many advantages and they can be any power in some place to work.They are a key technology that supports the modern world's demand for portable, efficient, and reliable power sources. Their versatility and performance make them a cornerstone of many industries and technologies.

Brief Guide to Installing Lithium Batteries：

1.Safety First: Always ensure that the device is turned off and disconnected from any power source before beginning the installation process.

2.Locate the cell Compartment: Find the battery compartment on your device, which is usually indicated by a battery icon or a compartment door.

3.Remove the Old Cell: If replacing an old battery, carefully remove it by sliding or lifting it out of the compartment. Be mindful of any locking mechanisms or clips that may hold the battery in place.

4.Inspect the New cell: Check the new lithium battery for any damage or defects. Ensure that it is the correct model and capacity for your device.

5.Insert the New cell: Place the new battery into the compartment, ensuring that the positive (+) and negative (-) terminals align correctly with the device's battery contacts.

6.Secure the cell: If there are any clips or locks, make sure they are engaged to secure the battery in place.

7.Close the Compartment: Close the battery compartment door or cover, ensuring it is properly sealed.

8.Reconnect Power: If necessary, reconnect any power sources and turn on the device to ensure the new battery is working correctly.

9.Charge the cell: If the cell is not pre-charged, connect the device to a charger and allow the battery to charge to its full capacity.

10.Monitor the Device: After installation, monitor the device for any signs of overheating or malfunction, which could indicate an issue with the cell installation.

Battery for solar power system home energy:

Model: BR-48100-3U

Battery Type: LiFePo4 (Lithium Iron Phosphate)

Nominal Voltage: 51.2V

Nominal Capacity: 100Ah

Nominal Energy: 5.12kWh

Usable Energy (90%DOD - Depth of Discharge): 4.6kWh

Internal Impedance: ≤100mΩ

Charge Voltage: 58.4V

Discharge Cutoff Voltage: 40V

Standard Charge Current: 20Ah

Maximum Charge Current: 100Ah

Standard Discharge Current: 20Ah

Maximum Discharge Current: 100Ah

Peak Discharge Current: 200A for less than 5 seconds

Operating Temperature (Charge): 0°C - +45°C

Operating Temperature (Discharge): -22°C to +55°C

Scalable: 1-6 in parallel

Enclosure Protection Rating: IP20

Net Weight (N.W.): 30KG

Dimensions: 440mm x 145mm x 560mm

Cubic Meter (CBM): 0.04m³

This information provides a detailed specification of the BR-48100-3U LiFePo4 battery, including its technical parameters and physical characteristics.

If you have any question about this product please feel freely to contact us via yan@bristarxm.com
